Model No: MD3570D
3570D Coreless Brushed DC Motor Low Noise Copper Winding High Efficiency for Medical & Industrial Equipment
Nominal voltage: 12 ~ 48 V DC
No-load speed : 1630 ~ 7850 RPM
Stall torque: 194 ~ 1212 mNm
Stall current: 0.71 ~ 55.56 A
Diameter: 35.0 mm
Length: 70.0 mm
Typical Application:
Industrial Equipment
Medical machine
No-load speed : 1630 ~ 7850 RPM
Stall torque: 194 ~ 1212 mNm
Stall current: 0.71 ~ 55.56 A
Diameter: 35.0 mm
Length: 70.0 mm
Typical Application:
Industrial Equipment
Medical machine
| 1 | Model | MD3570D | -01 | -08 | -04 | -09 | -14 |
| 2 | Rated Voltage | V DC | 19 | 15 | 18 | 24 | 48 |
| 3 | No-Load Speed | RPM | 6020 | 7200 | 4100 | 7750 | 5990 |
| 4 | No-Load Current | mA | 130 | 188 | 110 | 128 | 46 |
| 5 | Stall Torque | mNm | 1115.743 | 945.939 | 641.35 | 1211.906 | 777.816 |
| 6 | Stall Current | A | 37.255 | 47.923 | 15.517 | 41.237 | 10.256 |
| 7 | Rated Speed | RPM | 5660 | 6748 | 3754 | 7318 | 5588 |
| 8 | Rated Torque | mNm | 66.024 | 59.364 | 54.191 | 67.625 | 52.208 |
| 9 | Rated Current | A | 2.327 | 3.184 | 1.412 | 2.422 | 0.731 |
| 10 | Rated Output Power | W | 39.13 | 41.95 | 21.3 | 51.82 | 30.55 |
| 11 | Maximun Efficiency | % | 89 | 88 | 84 | 89 | 87 |
| 12 | Maximun Output Power | W | 175.73 | 178.31 | 68.84 | 245.89 | 121.98 |
| 13 | Terminal Resistance | Ω | 0.51 | 0.313 | 1.16 | 0.582 | 4.68 |
| 14 | Current Constant | A/mNm | 0.033 | 0.05 | 0.024 | 0.034 | 0.013 |
| 15 | Torque Constant | mNm/A | 30.054 | 19.816 | 41.627 | 29.48 | 76.179 |
| 16 | Speed Constant | RPM/V | 318 | 482 | 229 | 324 | 125 |
| 17 | Friction Torque | mNm | 3.907 | 3.725 | 4.579 | 3.773 | 3.504 |
| 18 | Speed/torque gradient | RPM/mNm | 5 | 8 | 6 | 6 | 8 |
