Model No: MD1642
1642 Coreless Permanent Magnet 16mm 24V 48V DC Brushed Motor High Efficiency ROHS Certified for Smart Home Applications
Typical Application:
Model Train
Toy
Speed Reducer
Model Train
Toy
Speed Reducer
| 1 | Model | MD1642 | -01 | -03 | -04 | -07 | -02 |
| 2 | Rated Voltage | V DC | 6 | 9 | 12 | 24 | 48 |
| 3 | No-Load Speed | RPM | 6000 | 6000 | 6000 | 6000 | 5500 |
| 4 | No-Load Current | mA | 18 | 13 | 10 | 4 | 2 |
| 5 | Stall Torque | mNm | 26.483 | 27.562 | 27.084 | 25.048 | 24.932 |
| 6 | Stall Current | A | 2.791 | 1.957 | 1.429 | 0.665 | 0.31 |
| 7 | Rated Speed | RPM | 5480 | 5528 | 5460 | 5542 | 5167 |
| 8 | Rated Torque | mNm | 2.134 | 2.254 | 2.274 | 1.949 | 2.01 |
| 9 | Rated Current | A | 0.241 | 0.172 | 0.129 | 0.055 | 0.027 |
| 10 | Rated Output Power | W | 1.22 | 1.3 | 1.3 | 1.13 | 1.09 |
| 11 | Maximun Efficiency | % | 85 | 84 | 84 | 85 | 85 |
| 12 | Maximun Output Power | W | 4.13 | 4.34 | 4.23 | 3.94 | 3.67 |
| 13 | Terminal Resistance | Ω | 2.15 | 4.6 | 8.4 | 36.1 | 155 |
| 14 | Current Constant | A/mNm | 0.105 | 0.071 | 0.052 | 0.026 | 0.012 |
| 15 | Torque Constant | mNm/A | 9.551 | 14.181 | 19.092 | 37.904 | 81.033 |
| 16 | Speed Constant | RPM/V | 1000 | 673 | 500 | 252 | 118 |
| 17 | Friction Torque | mNm | 0.172 | 0.184 | 0.191 | 0.152 | 0.162 |
| 18 | Speed/torque gradient | RPM/mNm | 225 | 218 | 220 | 240 | 225 |
